Five Advantages Of Products

  • It is waterproof, dustproof, easy to clean and durable
  • Without battery, directly convert light energy into electrical energy to charge electronic products
  • Light weight and easy to carry
  • With four mounting buckles, you can hang the product on the backpack
  • sunpower more efficient photoelectric conversion efficiency

Product Details

Peak power Pm(W) 6±3%

Open circuit voltage Voc(V) 7.2

Max. power voltage Vmp(V) 6

Max. power current Imp(A) 1.2

Short circuit current Isc(A) 1.28

Solar cells Efficiency 22-23%

Folding size/open size/weight 315*176*4mm/0.21 kgs

solar cell / No. of cells and connections sunpower /12 series

Solar panel front cover(material/thickness) Frosted PET/0.2mm; or ETFE/0.025mm

Encapsulant(material) Ethylene vinyl acetate(EVA)

Cloth/ Color 1000Dcloth/optional

Junction box protection degree ≥IP65

Cable /Cable connector Model 2-4SQMM, USB/MC4/5521/SAE

STC Irradiance:1000W/m2,Cell temperature:25ºC,AM:1.5

Solar panel back material glass fiber PCB0.6mm/TPT0.2mm

Output USB:5V1.2A

Max. hailstone impact (diameter/velocity) 25mm/ 23m/s

Max. system voltage (V) 1000V DC

Application Class Class A

NOCT 48±2ºC

Operating temperature limits -40ºC- +85ºC

Coefficient current TK 0.1%/ºC

Coefficient voltage TK -0.37%/ºC

Coefficient power  TK -0.45%/ºC

Life PET≥5 years; ETFE: ≥15 years

Warranty PET Cover: 2 years; ETFE: 5 years

Product Certification / Standard TUV,CE,ROHS,FCC,PSE/(IEC61215&IEC61730)
